📌 Key Specifications

ParameterDetailsModelLUX-12100FPBattery TypeLiFePO4 (Lithium Iron Phosphate)Nominal Voltage12.8VCapacity100AhEnergy1280WhCell TypePrismatic 100AhConfiguration4S1PMax Charge Current100AMax Discharge Current100AFull Charge Voltage14.6VCut-off Voltage10VInternal Resistance≤50mΩWeight12.5KgSize326 × 171 × 215 mmWaterproof RatingIP65TerminalScrew Terminal

🔄 Cycle Life Performance

• 🔹 100% DOD → 2000+ cycles
• 🔹 80% DOD → 3000+ cycles
• 🔹 50% DOD → 5000+ cycles

👉 Meaning: If used properly at 80% depth of discharge, battery can last 8–10 years easily.

🌡 Operating Temperature

• Charging: 0°C to 55°C
• Discharging: -20°C to 60°C

Optional Heating Function available for cold regions.

📲 Smart Features (Optional)

• ✔ LCD Display (Voltage & Power %)
• ✔ Bluetooth Monitoring (Mobile App)
• ✔ Series & Parallel Connection Support (Up to 48V system)

✅ Suitable For:

• IPS / Home Backup
• Solar Energy Storage
• Office Backup System
• Electric Vehicle (Customized Setup)
• Telecom Backup

⚡ Engineering Notes (For You Eng. Kawser)

Since you work with lithium and IPS systems at DeshiPower, this battery is perfect for:

• 1–2 hour heavy load backup (Fan, Light, TV, Router, Small Fridge)
• 1C discharge capability (100A = 1280W approx at 12.8V)
• Can connect 4 units in series → 51.2V 100Ah (≈5.12kWh system
